IP Camera--H.264 IP Camera
4MP、3MP HD resolution,clear and fine images;Support 2D/3D noise reduction,digital wide dynamic;Advanced H.265/H.264 video compression;Super low rate,high defini
- Previous:No record Next:IP Camera 1
Detailed introduction:
4MP、3MP HD resolution,clear and fine images;
Support 2D/3D noise reduction,digital wide dynamic;
Advanced H.265/H.264 video compression,Super low rate,high definition quality of image;
Professional anti-lightning,conform to GB/T17626.5 and IEC61000-4-5。
Support ONVIF ,access third party；
Support various mobile monitoring(iPhone,Android);
Provide web、CMS、center platform management software MYEYE,provide SDK development
Support cloud service, network penetration, alarm information pushed to phone ,etc.
| Model | IPX-40PB-1 | IPX-B40PB-1 |
| System structure | Embedded RTOS,dual-core 32bit DSP(Hi3516D),pure hard compression ,watch dog | |
| Sensor | 4.0M 1/3" Wide Dynamic low illumination CMOS；color 0.01Lux@F1.2,black/white 0.001Lux@F1.2 | |
| Video compression | H.265/H.264,support dual stream,AVI;0.1M~10Mpbs variable;1~30f/s variable | |
| Image output | Main stream:4MP 2560*1440@25fps,3MP 2048*1536@25fps;sub-stream: 704*576 @15fps | |
| Noise reduction | Support 2D/3D | |
| Wide dynamic | Support DWDR; | |
| Audio interface | 1ch input,level:2Vp-p,impedance:1kΩ,support sound pick-up input;1ch output,impedance:16Ω,30mw,support microphone; | |
| Audio compression | G.711,support bidrectional talk,audio&video synchronization; | |
| Network interface | 1*RJ45 10/100M adaptive Ethernet port;support RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP etc | |
| USB interface | 1*USB,support WIFI/3G | |
| Auto iris | No | One auto iris interface,support DC drive |
| Singal interface | One photo resistance interface,one IR-CUT interface ,support photo resistance signal and IR-CUT links to IR | |
| PTZ | 1*RS485,support kinds of PZT protocols | |
| Alarm I/O | 2/0 (support alarm input and video link to background) | 2/1 (support alarm input and video link to background) |
| SD Card | Unsupport | Support |
| Reliability | Comprehensive lightning protection, in line with national and international standards; 7 * 24 hours 65 ℃ high temperature stable and reliable testing (including mounted machine testing) | |
| Other function | Support WEB,OSD,live video transmission,motion detect and IO alarm,front-end storage/playback/download, and center reminder and image linkage,support JPEG capture；united remote client monitoring sofaware、MYEYE;perfect SDK; | |
| ONVIF | Support | |
| Mobile monitoring | Support multiple mobile monitoring（iOS，Android） | |
| Other | DC12V/2A input, power consumption:≤3W,dimension 38mm*38mm | |
| WIFI interface | N/A | |
| Reset | N/A | |
| interface | ||
| SD Card | N/A | |
| Reliability | Comprehensive lightning protection, 7 * 24 hours 65 ℃ high temperature stable and reliable testing | |
| Intelligence | Support | |
| analysis | ||
| Other function | Support OSD,live video transmission,motion detect and IO alarm,front-end storage/playback/download, and center reminder and image linkage,support JPEG capture；united remote client monitoring sofaware、MYEYE;perfect SDK; | |
| ONVIF | Support | |
| Mobile monitoring | Support multiple mobile monitoring（iOS，Android） | |
| Power | DC12V/2A input, power consumption:≤3W, | |
